It is suitable for labeling on the upper plane, curved surface and concave surface of products. The precision of labeling is to ±0.5 mm. It is mainly used for labeling of electronic component and digital products, such as toys, SD cards, mobile phone batteries, FPC, mobile phone chargers, etc. High-precision labeling, show the excellent quality of products, improve competitiveness.
APPLICATION:
OPERATION PROCESS:
Put the product on machine — Affix the label (Automatic device implementation) — Take out the labeled product.
TECHNICAL PARAMETER:
| Labeling accuracy | ± 0.5mm (Not include product and label errors) |
| Labeling speed | 15~30pcs/min (influenced by the size of the product and label)
|
| Suit product size | L:20~120mm W:20~180mm H:0.2~75mm
|
| Suit label size | L: 20mm-300mm W:20-130mm |
| Machine size | about 880mm*560mm*880mm (length*width*height)
|
| Voltage | 220V/50HZ |
| Machine weight | About 60KG |
| The label inner diameter | φ76mm |
| The label outer diameter | φ300mm |
| Air pressure | 0.4~0.6Mpa |
