FEATURE:
1. Easy to operate and maintain.
2. Automatic filling, welding, cutting and trimming in one time.
3. Stainless steel machine body, strong and beautiful looks,
4. Sealing mould can be customized according to customer requirements. Can seal many sizes of tubes.
5. Ultrasonic Sealing Machine power source for the pneumatic, working steady, not easy to damage, customers can rest assured use.
6. Ultrasonic frequency can meet international standard, no harmful to human being or environment
Such as food, medical, cosmetic products. It will not be hurting the products.
2. Overload protection, phase separation protection, power-fail protection.
3. Large Ultrasonic output power to ensure the sealing quality of various tube size and material.
4. With tube end trimming
5. Easy change working mold for difference tube diameter
6. Adjustable tube length.
7. Machine include a gear pump filler (Good filling precision+- 1)
TECHNICAL PARAMETER:
| Model | CE-006S-HX |
| Brand | FULLWELL |
| Frequency | 20kHz |
| Power | 2kw |
| Power Supply | AC220V/110V Single Phase 50/60Hz |
| Filling Range | A: 3-30ML
B: 6-60ML C: 10-120ML D: 25-250ML E: 50-500ML |
| Filling Accuracy | ±1% |
| Capaciy | 20-28pcs / min |
| Sealing Diameter | 10-50mm (Custom – made available) |
| Tube Height | 10-250mm |
| Air pressure | 0.6MPA |
| Air Consumption | 0.35m3/min |
| Dimension | 1300 x 900 x 1550mm |
| Net Weight | 320kg |
