SCREW CAPPING MACHINE – WITH CAP FEEDER- CE-1A/XGJ

Looking for Enquiry?

Ask for a quotation now and let us serve you!

Features

The capping machine is based on the international advanced models to improve the design, quick capping speed, high pass rate and convenient operation.

Applicable to different bottle-shaped screw caps in the food, pharmaceutical, cosmetic, pesticide, cosmetics and other industries.

The speed motors are used for capping, bottle clamping, conveying and capping respectively. The machine is highly automated and stable.

Easy to use, no spare parts required when replacing bottles or caps, just make adjustments





AUTOMATIC CAPPING MACHINE FEATURE:

  • Electrically controlled motion, strong stability
  • With positioning device, screw cap standard
  • Easy operation
  • Wide range, can lock bottle caps of different shapes and sizes
  • Solve the nozzle, pump head, spray pump, hand button nozzle
  • Difficult to screw cap
  • The speed of the cap is adjustable, and the tightness can be adjusted according to different caps.



AUTOMATIC CAPPING MACHINE HIGHLIGHT:

  1. Stainless steel + lightweight aluminum production
  2. The machine has good compatibility, can apply a variety of common caps. And the operation is simple.
  3. Excellent flexibility, can be adjusted according to the bottle height and cap size, elastic according to customer requirements adjust.
  4. The cover cover wheel wear-resistant silicone, does not hurt the cap.
  5. On the duckbill cover (pump head, nozzle,) more advantages, uniform mouth direction.
  6. Can be used in the filling production line.



Video

TECHNICAL PARAMETER:

Model CE-1A/XGJ
Brand FULLWELL
Supply voltage AC 220/ 50Hz
Power 1.5kw
Sealing bottle height(mm) 50-300 (can be customized)
Adapt to the cover diameter (mm) 30-80 (can be customized)
Working pressure (mpa) 0.6-0.8
Production (bottles/minute) 30-50/minute
Dimension (LxWxH) mm 1800 x 1100 x 1650
Net weight (kg) 380
